overview
Jack for Cat6 system, no cover, no tools required.
Describe
Modular Jack, Cat6, 22~26AWG, Phosphor Bronze, Polycarbonate
Implementation standards
ANSI/TIA568C.2,ISO/IEC11801-1:2008,YD/T1019-2013,YD/T926.2-2009
Quality warranty
15 year warranty
| Product type | Modular Jack (no tools required) |
| Performance level | Category 6 |
| Shield type | UTP |
| Wire | T568B |
| Conductor size (AWG) | 22~26AWG |
| Implementation standards | ANSI/TIA568C.2,ISO/IEC11801-1:2008,YD/T1019-2013,YD/T926.2-2009 |
| Application support | 1000BASE-T, 100BASE-T, 10BASE-T, IEEE 802.3af (Category 1 PoE), IEEE 802.3at (Category 2 PoE), IEEE 802.3bt (Category 3 PoE), IEEE 802.3bt (Category 4 PoE) |
| Minimum dielectric withstand voltage (contact to contact) | 1000V DC or AC peak |
| Compatibility | Back to Cat5e |
| Power over Ethernet | PoE(Type 1/2/3/4) & PoE+ |
| Operating temperature (℃) | -10~60℃ |
| Fire protection | UL1581, CM level, IEC 60332-1-2, GB/T 18380.12-2008 |
| Green | RoHS |
| Number of plug and unplug cycles | Plug>1000, finish>250 |
| Minimum latch holding force | 50N |
| Plug compatibility | RJ45 |
| Fluke standards | Fluke Fixed Link Tester |
| Standard quantity | 1 piece |
To evaluate the transmission performance of the module, we need to use Fluke test equipment for testing.
Only through the Fluke Fixed Link Test Module can it be determined whether it can meet the transmission requirements of a gigabit network.
Only T568B, makes operation clear and easy
